Outdoor Infrared Surveillance Long Range Uncooled PTZ Thermal Imaging Camera

Model NO. SHR-TIR63R Sensor CMOS HDMI Format 1080P Horizontal Resolution 324X256 Resolution Kind Autofocus Lens Certification CE, FCC, CCC, RoHS, ISO9001: 2000 Feature Waterproof / Weatherproof, High Definition, Vandal-proof Effective Distance ≧30m Remote Control With Remote Control Thermal Lens F Value 1.0 Thermal Lens Focal Length 20~60mm, 3X Optical Zoom Thermal Lens Control Electronic Zoom/Focus(Auto Focus Is Optional) Detector Type Uncooled Fpa Detector(Vox) Detector Resolution 324X256,Pixel 25um Netd Less Than 50mk Video Output PAL Power Interface DC12V Protection Grade IP66 Transport Package Carton/Wooden Package Specification 251mmx115mmx117mm Trademark CZVZ Origin Shandong, China Production Capacity 1000set/Month

Packaging & Delivery

Package Size 26.50cm * 18.00cm * 43.20cm Package Gross Weight 12.000kg

Product Description

Outdoor Infrared Surveillance Long Range Uncooled PTZ Thermal Imaging Camera Product Description



Product Features1. 324×256 High resolution uncooled microbolometer infrared focal plane arrays,vox2.25µm super small pixel,image quality fine,observe small target more clearly,further detection distance 3.High sensitivity, NETD can reach 50mk and frame at 25Hz 4.Word originate 20~60mm continuous zooming,can search in a wide range as well as identify target far,don't lost target 5.Image noise reduction processing,add DDE function; output hot white/ hot black/pseudo color6. Low power consumption, quick start-up, stable performance, image clearly with high uniformity 7.RS 485 interface control, analog video signal output 8.Simple operation,easy to use and maintain9. Precision casting aluminium alloy shell,sealed and waterproof,nitrogen inside, anti-harsh environment,overlength working lifetime  Technical Data:                      Model                                                   SHR-TIR63 Monitoring distance Object Human(1.8mx0.5m) Vehicle(2.4mx2.4m) Detection 1440mm 3960mm Recognition 360mm 990mm Identification 180mm 480mm Thermal lens Focal length 20~60nm, 3x optical zoom FOV 7.6°x 6.1° ~ 22.6°x18.2° F value F1.0 Lens control E-zoom, E-focus(auto focus is optional) Detector Type Uncooled FPA detector (vox) Resolution 324x256, pixel 25um Spectrum 8-14um NETD ≤50mK Frame rate 25Hz FFC Auto/manual/background correction Image process DDE, pseudo color Video output PAL Interface Power supply AC 24V±20%, 50/60Hz; DC 28V±20% Other interface RS485,BNC Video output Environmental indicators Working temperature -25ºC~÷55ºC Storage temperature -40ºC ~÷65ºC Anti-Vibration GB/T 4857.10-2005 Anti-impact GB/T 15412-94 Free drop test method Anti-thunder 2000V Protection level IP66 Physical features Weight ≤1.8kg Size(including sunshield cover) 251mmx115mmx117mm (LXWXH) Installation Outdoor base installation      Packaging & Shipping



   Package&Shipment:   Wooden / carton package means will be supplied to ensure the transport safety. FAQ

  FAQ:

1. Q: Is your company manufacturer?           Yes, CZVZ is the thermal camera and laser camera manufacturer since year 2004. 2. Q: Can you supply OEM service?          Yes, CZVZ can do OEM products as customer's requirement. 3. Q: What is the product's lead time?          It is confirmed by the order quantity. 4. Q: What is the warranty?          It is generally 1 year warranty, extend warranty is available. 5. Q: How will the product be shipped?          For sample order, it will be shipped by DHL, FEDEX, UPS or TNT.          For bulk order, we can arrange the shipment as customer requirement. 6. Q: How about your after sale service?          Any problem about our product, you can contact with us at any time. Our team will supply technical service for you. Company Profile



Company Introduction: CZVZ company, which was founded in year 2004, is one of the largest manufaturer of long range thermal imaging camera and laser night vision camera, as well as a relying Academician serveillance Engineering Technology Research Center in China. CZVZ adheres to independent innovation, which developed the world's first laser night vision camera,  and the continuous zoom infrared thermal imaging technology has reached the international advanced standard level.  The laser night vision and infrared thermal imaging products have been widely used in nation defense, safe cities, railways, highways, forest fire, oil and other fields, achieved all-weather surveillance, provided technical support for the maintenance of national security and socal stability. The company photo:  The exhibition:   You may also like, for detail information, please click below picture
