Military Used Dual Fov Thermal Camera

Model NO. SHR-TIR30-90R Sensor CMOS HDMI Format 1080P Horizontal Resolution 540tvl Kind Autofocus Lens Certification CE, FCC, ISO9001: 2000 Feature Waterproof / Weatherproof, High Definition, Vandal-proof Effective Distance 1.5 Km Sensor Size 1/3 inch Remote Control With Remote Control Weight ≤2kg Transport Package Box Specification 216mm× 106mm× 109mm Trademark CZVZ Origin Shandong Province, China Production Capacity 200 Units / Month

Packaging & Delivery

Package Size 45.00cm * 40.00cm * 35.00cm Package Gross Weight 10.000kg

Product Description

Features   Uncooled microbolometer infrared focal plane arrays,vox 25µm pixel, image quality fine, observe small target more clearly, further detection distance High sensitivity, NETD can reach 50mk and frame at 25Hz, good fog penetrate Dual FOV lens, can expand the search scope, and also identify distant goals, do not lose the target, switch quickly Advanced image noise reduction process, DDE(digital image details enhancement) function, outputting hot white/ hot black/ pseudo color image Low power consumption, quick start, stable performance Standard RS485 interface control, analog video signal output Simple operation, easy to use and maintain Precision cast aluminium alloy housing, seal waterproof, nitrogen inside, anti-harsh environment, super long work life Technical data   Model SHR-TIR30/90RMonitoring DistanceObjectHuman(1.8m×0.5m)Vehicle(2.3m×2.3m)Detection720/2160m1980/5940mRecognition180/540m490/1480mIdentification90/270m240/720mDetectorTypeUncooled microbolometer FPA (Vox)Resolution324×256, pixel 25μmSpectrum8~14μmNETD≤50mKFrame25HzFFCAuto/ manual/ background correctionImage processDDE/pseudo colorVideo outputPAL/NTSCLensFocal length30/90mm, dual FOV lensFOV15.4°×12.2°/5.2°×4.1°F valueF1.0Lens controlE-zoom/focusInterfacePowerDC12VOthersRS485, BNC video outputEnvironmental indicatorsOperation temperature-25ºC~ +55ºC(-40ºC~ +55ºC customized)Storage temperature-40ºC~ +65ºC ProtectionIP66Vibration10~ 55Hz, 0.75mmAnti-impact150m/s², 11msSalt-fog proof PH 6.5~7.2, continuously spraying 48 hours, surface with no changePowerWhole powerDC12V(Equip with AC220V/DC12V power adapter)Power consumption≤8WPhysical featuresWeight≤2kgSize216mm x 106mm x 109mmInstallation methodOutdoor base install
